Angle adjustment device夹角装置

Time: 2025-08-20 10:27:35.650

1. First, it is necessary to confirm whether this angle device can function properly (for intake and exhaust).
2. The intake and exhaust of the angle device should be correctly connected to the mold (after alignment, test by manually pressing the angle key. When the angle key is pressed, the angle cylinder inside the mold will move upward and then fall back).

3. The adjustment of the angle device's air pressure generally requires that the angle air pressure should be greater than the molding air pressure (0.1 - 0.2) MPa.
4. The operation of the cup-making machine usually involves (feeding the sheet - closing the mold - stretching - molding - cutting and shearing - opening the mold - topping the cup - blowing the cup). For angle products, the angle should be opened after the molding is activated and before the top is applied. The specific effect depends on the adjustment of time or angle based on the produced product.

1.首先要确认这套夹角装置是否可正常使用(进气出气)。
2.夹角装置的进气出气与模具要正确连接(对接后通过手动点夹角键测试，当点开夹角键模具里夹角气缸会有向上动作松开会落下)。
3.夹角装置气压的调节一般夹角气压需大于成型气压(0.1-0.2)MPa
4.制杯机通常动作为(送片-合模-拉伸-成型-冲剪-开模-顶杯-吹杯)，做夹角产品夹角在成型开启后再开启在顶杯之前要关闭，具体效果看做出来的产品对时间或角度进行调整。
