Shantou Longsheng Industry Co., Ltd.
SI-120-980-II Vertical Single-layer Sheet Extruder
Main features:
1, used in the production of polypropylene (PP), polyethylene (PE), polystyrene (PS) and other plastic sheets.
2, using large length-diameter ratio screw, plasticizing effect is better, pressure is more stable.
3, the die is made of alloy material, reasonable structure, wear resistance, uniform heat, easy adjustment.
4, melt metering pump quantitative pressure output, and equipment pressure and speed closed-loop automatic control.
5, three roller independent adjustment is consistent, synchronous adjustment operation is convenient.
6, equipped with double station electric winding, easy to change, winding flat, reduce waste.
7, the use of PLC control, to achieve parameter setting, data calculation and feedback, alarm and other functions of automatic control.
extruder screw | One φ120 single screw |
Maximum extrusion output | φ120≤350kg/h |
Handle materials | PS, PP, PE and other materials |
Product Specifications | Width ≤880mm, thickness 0.3-2.5mm |
The thickness of the product | ±0.01mm |
The maximum diameter of the wound | 1200mm |
Equipment footprint | About L=12M,W=2.5M,H=3M |
Roller specification | Φ400×980mm=2pcs，Φ520×980mm=1pcs， |
Power | 380V/50HZ+E（三相四线制） 380V/50HZ+E (three-phase four-wire system) |
Air Source | 0.8Mpa |
cooling water | Soft water in medium at 5 to 25 degrees Celsius |
total power | About 220Kw/h |
MADE IN CHINA
